ALS Type Forklift Fuse | 200A / 250A / 300A

ALS Type Forklift Fuse — 200A / 250A / 300A

Keep your forklift running safely and reliably with our OEM-quality ALS Series fuse strips. Engineered to handle the demanding electrical loads of industrial forklifts, these fuses provide dependable overcurrent protection for both AC and DC systems. Fully work-safe compliant and built to last.

Please select your required amperage at checkout: 200A / 250A / 300A.

Key Features

• ALS Series fuse strip — industry-standard design for forklift applications
• Available in 200A, 250A, and 300A ratings
• Rated for 125V AC/DC systems
• Self-extinguishing housing (200A & 250A variants)
• Durable plastic housing for reliable insulation and protection
• Under-side fixing hole position for secure mounting
• OEM quality — direct replacement for original equipment
• Fully work-safe compliant

Specifications by Amperage

200 AMP

• Current: 200A | Voltage: 125V AC/DC
• Total Length: 118.0 mm
• Fuse Tube Diameter: 27.0 mm
• Housing Length: 59.0 mm | Housing Material: Plastic
• Connection Width: 25.5 mm
• Centre Distance Between Fixing Holes: 93.0 mm
• Fixation Hole Diameter: 9.6 mm (x2, under-side)
• Self-Extinguishing: Yes

250 AMP

• Current: 250A | Voltage: 125V AC/DC
• Total Length: 118.7 mm
• Fuse Tube Diameter: 27.0 mm
• Housing Length: 58.7 mm | Housing Material: Plastic
• Connection Width: 25.5 mm
• Centre Distance Between Fixing Holes: 93.5 mm
• Fixation Hole Diameter: 9.7 mm (x2, under-side)
• Self-Extinguishing: Yes

300 AMP

• Current: 300A | Voltage: 125V AC/DC
• Total Length: 118.0 mm
• Fuse Tube Diameter: 27.0 mm
• Housing Length: 59.0 mm | Housing Material: Plastic
• Connection Width: 25.5 mm
• Centre Distance Between Fixing Holes: 93.5 mm
• Fixation Hole Diameter: 9.7 mm (x2, under-side)
• Self-Extinguishing: No

Condition

New — OEM quality replacement part. Supplied in original packaging.

Potential Applications

Suitable for use in electric and LPG forklifts across a wide range of brands including Nissan, Toyota, Hyster, Yale, Komatsu, Clark, Caterpillar, and more. Ideal for fleet operators, workshop technicians, and maintenance teams requiring a reliable, direct-fit fuse replacement.

Warranty

2-Year Warranty — All ALS fuses are backed by a 2-year warranty, giving you confidence in every installation.
